型号 | 额定电压 (V) | 5hr额定容量 (Ah) | 最大外形尺寸(mm) | 极柱数量 | 容器材料 | |||||
本厂型号 | 标准型号 | 长 | 宽 | 槽高 | 总高(焊) | 总高(活) | ||||
2VBS100 | D-100-Z2 | 2 | 100 | 45 | 158 | 385 | 420 | 430 | 2 | PP |
3VBS150 | D-150-Z3 | 2 | 150 | 61 | 158 | 385 | 420 | 430 | 2 | PP |
4VBS200 | D-200-Z4 | 2 | 200 | 77 | 158 | 385 | 420 | 430 | 2 | PP |
5VBS250 | D-250-Z5 | 2 | 250 | 93 | 158 | 385 | 420 | 430 | 2 | PP |
6VBS300 | D-300-Z6 | 2 | 300 | 109 | 158 | 385 | 420 | 430 | 2or4 | PP |
7VBS350 | D-350-Z7 | 2 | 350 | 125 | 158 | 385 | 420 | 430 | 2or4 | PP |
8VBS400 | D-400-Z8 | 2 | 400 | 141 | 158 | 385 | 420 | 430 | 2or4 | PP |
9VBS450 | D-450-Z9 | 2 | 450 | 157 | 158 | 385 | 420 | 430 | 2or4 | PP |
10VBS500 | D-500-Z10 | 2 | 500 | 173 | 158 | 385 | 420 | 430 | 2or4 | PP |
11VBS550 | D-550-Z11 | 2 | 550 | 189 | 158 | 385 | 420 | 430 | 4 | PP |
12VBS600 | D-600-Z12 | 2 | 600 | 205 | 158 | 385 | 420 | 430 | 4 | PP |
13VBS650 | D-650-Z13 | 2 | 650 | 221 | 158 | 385 | 420 | 430 | 4 | PP |
14VBS700 | D-700-Z14 | 2 | 700 | 237 | 158 | 385 | 420 | 430 | 4 | PP |
15VBS750 | D-750-Z15 | 2 | 750 | 253 | 158 | 385 | 420 | 430 | 4 | PP |
2VBS110 | D-110-Z2 | 2 | 110 | 45 | 158 | 405 | 440 | 450 | 2 | PP |
3VBS165 | D-165-Z3 | 2 | 165 | 61 | 158 | 405 | 440 | 450 | 2 | PP |
4VBS220 | D-220-Z4 | 2 | 220 | 77 | 158 | 405 | 440 | 450 | 2 | PP |
5VBS275 | D-275-Z5 | 2 | 275 | 93 | 158 | 405 | 440 | 450 | 2 | PP |
6VBS330 | D-330-Z6 | 2 | 330 | 109 | 158 | 405 | 440 | 450 | 2or4 | PP |
7VBS385 | D-385-Z7 | 2 | 385 | 125 | 158 | 405 | 440 | 450 | 2or4 | PP |
8VBS440 | D-440-Z8 | 2 | 440 | 141 | 158 | 405 | 440 | 450 | 2or4 | PP |
9VBS495 | D-495-Z9 | 2 | 495 | 157 | 158 | 405 | 440 | 450 | 2or4 | PP |
10VBS550 | D-550-Z10 | 2 | 550 | 173 | 158 | 405 | 440 | 450 | 2or4 | PP |
11VBS605 | D-605-Z11 | 2 | 605 | 189 | 158 | 405 | 440 | 450 | 4 | PP |
12VBS660 | D-660-Z12 | 2 | 660 | 205 | 158 | 405 | 440 | 450 | 4 | PP |
13VBS715 | D-715-Z13 | 2 | 715 | 221 | 158 | 405 | 440 | 450 | 4 | PP |
14VBS770 | D-770-Z14 | 2 | 770 | 237 | 158 | 405 | 440 | 450 | 4 | PP |
15VBS825 | D-825-Z15 | 2 | 825 | 253 | 158 | 405 | 440 | 450 | 4 | PP |
2VBS120 | D-120-Z2 | 2 | 120 | 45 | 158 | 431 | 466 | 476 | 2 | PP |
3VBS180 | D-180-Z3 | 2 | 180 | 61 | 158 | 431 | 466 | 476 | 2 | PP |
4VBS240 | D-240-Z4 | 2 | 240 | 77 | 158 | 431 | 466 | 476 | 2 | PP |
5VBS300 | D-300-Z5 | 2 | 300 | 93 | 158 | 431 | 466 | 476 | 2 | PP |
6VBS360 | D-360-Z6 | 2 | 360 | 109 | 158 | 431 | 466 | 476 | 2or4 | PP |
7VBS420 | D-420-Z7 | 2 | 420 | 125 | 158 | 431 | 466 | 476 | 2or4 | PP |
8VBS480 | D-480-Z8 | 2 | 480 | 141 | 158 | 431 | 466 | 476 | 2or4 | PP |
9VBS540 | D-540-Z9 | 2 | 540 | 157 | 158 | 431 | 466 | 476 | 2or4 | PP |
10VBS600 | D-600-Z10 | 2 | 600 | 173 | 158 | 431 | 466 | 476 | 2or4 | PP |
11VBS660 | D-660-Z11 | 2 | 660 | 189 | 158 | 431 | 466 | 476 | 4 | PP |
12VBS720 | D-720-Z12 | 2 | 720 | 205 | 158 | 431 | 466 | 476 | 4 | PP |
13VBS780 | D-780-Z13 | 2 | 780 | 221 | 158 | 431 | 466 | 476 | 4 | PP |
14VBS840 | D-840-Z14 | 2 | 840 | 237 | 158 | 431 | 466 | 476 | 4 | PP |
15VBS900 | D-900-Z15 | 2 | 900 | 253 | 158 | 431 | 466 | 476 | 4 | PP |
2VBS140 | D-140-Z2 | 2 | 140 | 45 | 158 | 495 | 530 | 540 | 2 | PP |
3VBS210 | D-210-Z3 | 2 | 210 | 61 | 158 | 495 | 530 | 540 | 2 | PP |
4VBS280 | D-280-Z4 | 2 | 280 | 77 | 158 | 495 | 530 | 540 | 2 | PP |
5VBS350 | D-350-Z5 | 2 | 350 | 93 | 158 | 495 | 530 | 540 | 2 | PP |
6VBS420 | D-420-Z6 | 2 | 420 | 109 | 158 | 495 | 530 | 540 | 2or4 | PP |
7VBS490 | D-490-Z7 | 2 | 490 | 125 | 158 | 495 | 530 | 540 | 2or4 | PP |
8VBS560 | D-560-Z8 | 2 | 560 | 141 | 158 | 495 | 530 | 540 | 2or4 | PP |
9VBS630 | D-630-Z9 | 2 | 630 | 157 | 158 | 495 | 530 | 540 | 2or4 | PP |
10VBS700 | D-700-Z10 | 2 | 700 | 173 | 158 | 495 | 530 | 540 | 2or4 | PP |
11VBS770 | D-770-Z11 | 2 | 770 | 189 | 158 | 495 | 530540 | 4 | PP | |
12VBS840 | D-840-Z12 | 2 | 840 | 205 | 158 | 495 | 530 | 540 | 4 | PP |
13VBS910 | D-910-Z13 | 2 | 910 | 221 | 158 | 495 | 530 | 540 | 4 | PP |
14VBS980 | D-980-Z14 | 2 | 980 | 237 | 158 | 495 | 530 | 540 | 4 | PP |
15VBS1050 | D-1050-Z15 | 2 | 1050 | 253 | 158 | 495 | 530 | 540 | 4 | PP |
2VBS160 | D-160-Z2 | 2 | 160 | 45 | 158 | 554 | 589 | 599 | 2 | PP |
3VBS240 | D-240-Z3 | 2 | 240 | 61 | 158 | 554 | 589 | 599 | 2 | PP |
4VBS320 | D-320-Z4 | 2 | 320 | 77 | 158 | 554 | 589 | 599 | 2 | PP |
5VBS400 | D-400-Z5 | 2 | 400 | 93 | 158 | 554 | 589 | 599 | 2 | PP |
6VBS480 | D-480-Z6 | 2 | 480 | 109 | 158 | 554 | 589 | 599 | 2or4 | PP |
7VBS560 | D-560-Z7 | 2 | 560 | 125 | 158 | 554 | 589 | 599 | 2or4 | PP |
8VBS640 | D-640-Z8 | 2 | 640 | 141 | 158 | 554 | 589 | 599 | 2or4 | PP |
9VBS720 | D-720-Z9 | 2 | 720 | 157 | 158 | 554 | 589 | 599 | 2or4 | PP |
10VBS800 | D-800-Z10 | 2 | 800 | 173 | 158 | 554 | 589 | 599 | 2or4 | PP |
11VBS880 | D-880-Z11 | 2 | 880 | 189 | 158 | 554 | 589 | 599 | 4 | PP |
12VBS960 | D-960-Z12 | 2 | 960 | 205 | 158 | 554 | 589 | 599 | 4 | PP |
13VBS1040 | D-1040-Z13 | 2 | 1040 | 221 | 158 | 554 | 589 | 599 | 4 | PP |
14VBS1120 | D-1120-Z14 | 2 | 1120 | 237 | 158 | 554 | 589 | 599 | 4 | PP |
15VBS1200 | D-1200-Z15 | 2 | 1200 | 253 | 158 | 554 | 589 | 599 | 4 | PP |
2VBS180 | D-180-Z2 | 2 | 180 | 45 | 158 | 615 | 650 | 660 | 2 | PP |
3VBS270 | D-270-Z3 | 2 | 270 | 61 | 158 | 615 | 650 | 660 | 2 | PP |
4VBS360 | D-360-Z4 | 2 | 360 | 77 | 158 | 615 | 650 | 660 | 2 | PP |
5VBS450 | D-450-Z5 | 2 | 450 | 93 | 158 | 615 | 650 | 660 | 2 | PP |
6VBS540 | D-540-Z6 | 2 | 540 | 109, | 158 | 615 | 650 | 660 | 2or4 | PP |
7VBS630 | D-630-Z7 | 2 | 630 | 125 | 158 | 615 | 650 | 660 | 2or4 | PP |
8VBS720 | D-720-Z8 | 2 | 720 | 141 | 158 | 615 | 650 | 660 | 2or4 | PP |
9VBS810 | D-810-Z9 | 2 | 810 | 157 | 158 | 615 | 650 | 660 | 2or4 | PP |
10VBS900 | D-900-Z10 | 2 | 900 | 173 | 158 | 615 | 650 | 660 | 2or4 | PP |
11VBS990 | D-990-Z11 | 2 | 990 | 189 | 158 | 615 | 650 | 660 | 4 | PP |
12VBS1080 | D-1080-Z12 | 2 | 1080 | 205 | 158 | 615 | 650 | 660 | 4 | PP |
13VBS1170 | D-1170-Z13 | 2 | 1170 | 221 | 158 | 615 | 650 | 660 | 4 | PP |
, 14VBS1260 | D-1260-Z14 | 2 | 1260 | 237 | 158 | 615 | 650 | 660 | 4 | PP |
15VBS1350 | D-1350-Z15 | 2 | 1350 | 253 | 158 | 615 | 650 | 660 | 4 | PP |
2VBS200 | D-200-Z2 | 2 | 200 | 45 | 158 | 690 | 725 | 735 | 2 | PP |
3VBS300 | D-300-Z3 | 2 | 300 | 61 | 158 | 690 | 725 | 735 | 2 | PP |
4VBS400 | D-400-Z4 | 2 | 400 | 77 | 158 | 690 | 725 | 735 | 2 | PP |
5VBS500 | D-500-Z5 | 2 | 500 | 93 | 158 | 690 | 725 | 735 | 2 | PP |
6VBS600 | D-600-Z6 | 2 | 600 | 109 | 158 | 690 | 725 | 735 | 2or4 | PP |
7VBS700 | D-700-Z7 | 2 | 700 | 125 | 158 | 690 | 725 | 735 | 2or4 | PP |
8VBS800 | D-800-Z8 | 2 | 800 | 141 | 158 | 690 | 725 | 735 | 2or4 | PP |
9VBS900 | D-900-Z9 | 2 | 900 | 157 | 158 | 690 | 725 | 735 | 2or4 | PP |
10VBS1000 | D-1000-Z10 | 2 | 1000 | 173 | 158 | 690 | 725 | 735 | 2or4 | PP |
11VBS1100 | D-1100-Z11 | 2 | 1100 | 189 | 158 | 690 | 725 | 735 | 4 | PP |
12VBS1200 | D-1200-Z12 | 2 | 1200 | 205 | 158 | 690 | 725 | 735 | 4 | PP |
13VBS1300 | D-1300-Z13 | 2 | 1300 | 221 | 158 | 690 | 725 | 735 | 4 | PP |
14VBS1400 | D-1400-Z14 | 2 | 1400 | 237 | 158 | 690 | 725 | 735 | 4 | PP |
15VBS1500 | D-1500-Z15 | 2 | 1500 | 253 | 158 | 690 | 725 | 735 | 4 | PP |
